Description:

Small size, easy to use
Low voltage, low power consumption
High accuracy
Strong anti-jamming
Integrated with wire enclosed waterproof probe, suitable for wet, harsh measurement occasions

Specification:

1.Electrical parameters: JSN-SR04T
2.Operating voltage: DC 5V
3.Quiescent current: 5mA
4.Total current work: 30mA
5.Acoustic emission frequency: 40khz
6.Farthest distance: 4.5m
7.Blind: 25cm
8.Wiring: + 5V (positive power supply)
Trig (control side) RX
Echo (the receiver) TX
GND (negative)
9.Resolution: about 0.5cm
10.Angle: less than 50 degrees
11.Working temperature: -10 ~ 70 Celsuis
12.Storage temperature: -20 ~ 80 Celsuis
13.Size; 42x29mm/1.65x1.14inch; leading line: 98.43inch

Package Includes:

1 Piece Integrated Distance Measuring Sensor
